Dynon Avionics EMS-D10 - EMS SERIAL DATA OUTPUT

Appendix
8-2 EMS-D10 Pilot’s User Guide
EMS SERIAL DATA OUTPUT
The format for the data sent out the EMS RS232 port is:
Parameter
ASCII
Characters
Units Example
Zulu Hour 2 Hours 12 (12 hrs)
Zulu Min 2 Minutes 12 (12 mins)
Zulu Sec 2 Seconds 12 (12 secs)
Fraction 2 1/64 of sec 12 (12/64 sec)
Manifold Pressure 4 inHg x 100 1215 (12.15inHg) (using 5/100 increments)
Oil Temp 3 º F 123 (123
o
F) or -12 (-12
o
F)
Oil Pressure 3 PSI 099 (99PSI)
Fuel pressure 3 PSI x 10 123 (12.3psi)
Volts 3 volts x 10 123 (12.3V)
Amps 3 amps 012 (12A) or –12 (-12A)
RPM 3 RPM/10 123 (1230 RPM)
Fuel Flow 3 GPH x 10 123 (12.3gph)
Gallons remaining 4 Gallons x 10 1234 (123.4g) or –123 (-12.3g)
Fuel_Level_1 3 Gallons x 10 123 (12.3g)
Fuel_Level_2 3 Gallons x 10 123 (12.3g)
GP_1 8 See table below 3 char label; 5 char data; see GP output table
GP_2 8 See table below 3 char label; 5 char data; see GP output table
GP_3 8 See table below 3 char label; 5 char data; see GP output table
GP Thermocouple 4 ºF 1234 (1234
o
F) or –123 (-123ºF )
