Appendix
EMS-D10 Pilot’s User Guide 8-3
Parameter
ASCII
Characters
Units Example
EGT_1 4 ºF 1234 (1234
o
F) or –123 (-123ºF )
EGT_2 4
ºF
1234 (1234
o
F) or –123 (-123ºF )
EGT_3 4
ºF
1234 (1234
o
F) or –123 (-123ºF )
EGT_4 4
ºF
1234 (1234
o
F) or –123 (-123ºF )
EGT_5 4
ºF
1234 (1234
o
F) or –123 (-123ºF )
EGT_6 4
ºF
1234 (1234
o
F) or –123 (-123ºF )
CHT_1 3
ºF
123 (123
o
F) or –12 (-12ºF )
CHT_2 3
ºF
123 (123
o
F) or –12 (-12ºF )
CHT_3 3
ºF
123 (123
o
F) or –12 (-12ºF )
CHT_4 3 º F 123 (123
o
F) or –12 (-12ºF )
CHT_5 3 º F 123 (123
o
F) or –12 (-12ºF )
CHT_6 3 º F 123 (123
o
F) or –12 (-12ºF )
Contact_1 1
Boolean
‘0’ or ‘1’ indicating whether the contact is closed
or open
Contact_2 1
Boolean
‘0’ or ‘1’ indicating whether the contact is closed
or open
Product ID 2 ASCII hex Internal-use product ID
Checksum 2
ASCII hex
The self-zeroing ascii-hex 2-byte checksum. The
sum of the checksum with all preceding bytes
produces 0x00.
CR 1 0x13
LF 1 0x10
