service manual
Diagnostic
Action
Action
Possible cause
Possible cause
1
1
Check for blockages-see 'Loss of suction/pick up' page
Check motor (commutator, windings, carbon build-up, excess heat)
Symptom: Burning smell
Symptom: Thermal cut-out activating
Motor failure
Broken/worn belt (DC20
only)
Worn brushbar (DC20
only)
Restricted airflow
Motor failure
Action
Possible cause
Symptom: Noisy
Check all seals and airways-see 'Loss of suction/pick up' page
Check motor bucket seal for correct fit. Check post filter for blockages
Air leakage
Brushbar noise
Large object in bin
Motor failure
Check brushbar for obstructions, wear, incorrect fit
Empty bin
Check motor for loose impeller/nut/case, foreign objects in impeller, motor failure
No.
No.
No.
Replace Turbo head
Check brushbar for obstructions, wear, incorrect fit - replace
Check post filter for carbon build up. Check motor (commutator, windings, brushes,
carbon build-up)
2
1
2
15
