service manual
Parts recognition
LMC assy
HEPA Filter
A
ssy
HEPA Seal
Bumper Strip
Castor Body
Castor Roller
Post Filter
Cover
Post Filter
Scrim
Post Filter
Pad
Cyclone
Inlet Assy
Rear Wheel
Assy
Switch
Switch Holder
Cable Rewind
Assy
LMC Assy
Axle
Connection Insulator
Cyclone & bin assy
17
