E.C.A. Proteus Plus - Air;Flue Kit Components

- For room sealed fan assisted operation,
apart
from the
boiler
package,
concentric
air/flue
kit
( 60/100) is given with a cardboard box.
Air/flue kit consists of the following
parts:
a) Flat sealing ring
b) Flange
c) 90
0
Concentric elbow
d) Screws
e) Fixing Collar
f) Sealing ring, EPDM
g) Concentric Terminal (100mm)
h) Inner and outer flanges, EPDM, 2 pieces
