E.C.A. Proteus Plus - Horizontal Air;Flue Kit Accessories

fig. 9
Room Sealed Fan Assisted Operation
fig. 10
If the air/flue kit length is insufficient, additional flue
accessories qualified service. Do not use any other type / brand name of
flue parts.
should
be
ordered
through
- Horizontal air/flue kit accessories (fig 11):
a) Concentric extension, L=500 mm, 60/100 mm
Concentric extension, L=1000 mm, 60/100 mm
b) 90
0
Concentric elbow, 60/100 mm
c) 45
0
Concentric elbow, 60/100 mm
a)
b)
c)
fig. 11
13
