4 E-flite F-4 Phantom 32 DF Assembly Manual
Recommended Radio Equipment
You will need a minimum 5-channel transmitter,
receiver and seven servos.
Complete Radio System
SPM8800 DX8 DSM2
™
8CH system
8-channel receiver installation:
SPMAR8000 AR8000 DSMX 8-Channel Full-
Range Receiver
JSP20030 MC35 Servo (6)
JRPSDS3421 DS3421 Premium Digital Servo,
elevator
SPMA3058 Y-harness
SPMA3052 9-inch (228mm) servo extension
The extensions listed for the 8-channel
operation (separate ailerons and nose gear)
will require the use of mixing at the transmitter.
6-channel receiver installation:
SPMAR6210 AR6210 DSMX 6-Channel Full-
Range Receiver
JSP20030 MC35 Servo (6)
JRPSDS3421 DS3421 Premium Digital Servo,
elevator
SPMA3058 Y-harness (3)
SPMA3052 9-inch (228mm) servo extension
lightweight
The extensions listed for the 6-channel
operation will require surfaces (flaps, ailerons
and steering-to-rudder) using a Y-harness.
Motor Setup
EFLM3032DFA DF32 Brushless Motor, 2150Kv
EFLDF32 Delta-V
®
32 80mm EDF
EFLA1080B 80-Amp Pro SB
Brushless ESC v2
EFLB50006S30 5000mAh 6S 22.2V 30C Li-Po,
10AWG EC5
Optional Accessories
EFLC3025 Celectra
™
80W AC/DC Multi-
Chemistry Battery Charger
EFLA110 Power Meter
EFLAEC512 EC5
™
Device Charge Lead with
6-inch Wire and Jacks, 12AWG
PKZ7003 Pilot (2)
Optional Retracts
EFLG230 15–25 Tricycle Electric Retracts
SPMA3000 3-inch (76mm) Servo
Extension (2)
SPMA3004 18-inch (457mm) servo
extension
Optional Batteries
EFLB50006S50 5000mAh 6S 22.2V 50C Li-Po,
10AWG EC5
THP50006SPP65 5000mAh 6-Cell/6S 22.2V
G64 Pro Power 65C Li-Po
UltraCote
®
Covering Colors
Light Gray HANU882
True Red HANU866
Silver HANU881
White HANU870
Hardware/Accessory Sizes
Main wheel diameter 1
7
/
8
-inch (48mm)
Nose wheel diameter 1
5
/
16
-inch (33mm)
Wing bolt 8-32 x 1/4-inch
Required Tools and Adhesives
Tools & Equipment
Balancing stand Ball driver: 9/64-inch
Flexible tape Clear tape
Drill Coarse grit sandpaper
Epoxy brush Felt-tipped pen
Hobby scissors Low-tack tape
Mixing cup Mixing stick
Needle-nose pliers Paper towels
Pencil Petroleum jelly
Pin vise Razor saw
Rotary tool Rubbing alcohol
Ruler Sanding block
Sanding drum Scissors
Side cutter String
Tie-wraps Toothpick
Trim seal tool Two-sided tape
Flat file
Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm)
Hex wrench: 1.5mm, 2.5mm
Hobby knife with #11 blade
Medium grit sandpaper
Phillips screwdriver: #0, #1
Adhesives
5-minute epoxy PAAPT38
15-minute epoxy MEUEPX15MIN
CA accelerator PAAPT715
Canopy glue PAAPT56
Thin CA PAAPT08
Threadlock PAAPT42
Silicone adhesive DEVS250
