3E-flite F-86 Sabre 15 DF ARF Assembly Manual
Recommended Radio Equipment
You will need a minimum 4-channel transmitter,
receiver and five servos. You can choose to purchase
a complete radio system. If you are using an
existing transmitter, just purchase the other required
equipment separately. We recommend the crystal-
free, interference-free Spektrum
™
DX6i 2.4GHz DSM
®
6-channel system. If using your own transmitter, we
recommend the following radio equipment.
If you own the Spektrum DX6i radio, or you are using
a different DSM2 radio, just add the AR6200 DSM2
™
6-channel receiver, four E-flite S75 Sub-Micro servos
and one JR SPORT
™
MC35 servo
Complete Radio System
SPM6600 DX6i DSM2 6CH system
Or Purchase Separately
SPMAR6200 AR6200 DSM2 6-Channel Full-
Range Receiver (for DX6i or
DX7)
EFLRS75 7.5-Gram Sub-Micro S75
Servo (4)
JSP20030 MC35 Micro Servo
And
EFLREX9L 9-inch Extension, Lightweight (2)
Note: A Y-harness can be used for the for nose
gear steering if a computer radio with mixing
is not being used.
EFLRYH3 3-inch Y-Harness, Lightweight
Required Brushless Ducted Fan Setup
EFLM3215DF 15 DF Brushless Motor, 3200Kv
EFLDF15 Delta-V 15 (69mmm) Ducted
Fan Unit
EFLA1060 60-Amp Pro Switch-Mode
BEC Brushless ESC
EFLB32004S30 3200mAh 4S 14.8V 30C Li-Po,
13AWG EC3
Required Tools and Adhesives
Tools & Equipment
Epoxy brushes Felt-tipped pen
Hobby scissors Hobby knife (#11 blade)
Low-tack tape Hex wrench: 1.5mm
Mixing cups Sanding bar
Mixing sticks Needle-nose pliers
Paper towels Pencil
Petroleum jelly Phillips screwdriver: #0, #1
Pin vise Rubbing alcohol
Ruler Scissors
Side cutters Square
String/dental floss Toothpicks
T-pins Waxed paper
Sandpaper
Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm)
Adhesives
Threadlock 6-Minute Epoxy (HAN8000)
Thin CA 12-Minute Epoxy (HAN8001)
Medium CA
Optional Accessories
PKZ7003 Pilot: Habu
EFLA110 Power Meter
EFLC505 Intelligent 1- to 5-Cell
Balancing Charger
EFLAEC312 Charge Lead with 12-inch
wire and Jacks, 16AWG
Warnings
Read and follow all instructions and safety precautions
before use. Improper use can result in fire, serious
injury and damage to property.
COMPONENTS
Use only with compatible components. Should any
compatibility questions exist please refer to the product
instructions, the component instructions or contact
Horizon Hobby, Inc.
FLIGHT
Fly only in open areas to ensure safety. It is
recommended flying be done at AMA (Academy of
Model Aeronautics) approved flying sites.
PROPELLER
Keep loose items that can get entangled in the
propeller away from the prop, including loose clothing,
or other objects such as pencils and screwdrivers.
Especially keep your hands away from the propeller as
injury can occur.
BATTERIES
Notes on Lithium Polymer Batteries
Lithium Polymer batteries are significantly more
volatile than alkaline or Ni-Cd/Ni-MH batteries used
in RC applications. Always follow the manufacturer’s
instructions when using and disposing of any batteries.
Mishandling of Li-Po batteries can result in fire and
explosion causing serious injury and damage.
The Spektrum trademark is used with permission
of Bachmann Industries, Inc.
