e-Ink Spectra 3100 User Manual

1
Firmware Update SOP
1 Hardware Guide
(1) Hardware Requirements
Buy a set of MSP-EXP430G2
You will get following stuffs in the package
MSP-EXP430G2
(2) Hardware Installation
The programmer needs the jump line as the picture below
Connect to MSP430 and THOR MCU board
 Please connect the Dupont line from J3 (VCC pin) of MSP430 LaunchPad to J1's 2nd
pin of Thor
 Please connect the Dupont line from J3 (TEST pin) of MSP430 LaunchPad to J1's 8th
