3.6 DATA LOGGER
The nGauge will monitor and log all signals shown on the active gauge screen. It is also possible to monitor signals not shown on the
active gauge screen. This allows the user to view only the most valuable data, while still being able to review all the vehicle data in the
log file. The Global Data Logger can silently monitor up to 16 signals and will be logged with the active gauge screen data.
Using a tuner supplied config (.dle) file
1. Tap on [Diagnostics] from the Main Menu.
2. Tap on [ Datalogging].
3. Use [<] or [>] to select proper datalog config file downloaded to SD card from your tuner
4. Tap on [√] to accept
5. nGauge will connect
6. Tap on either box on the left side of the display to start logging. Logging is indicated by LED activity in the light centered
directly above the screen.
7. To stop datalogging, either exit out of the datalogger using the [x] button, or tap again on either box on the left side of the
display. The LED activity should cease
File will be stored on the SD card.
Creating your own datalogged pids to record to SD card.
1. Tap on [Gauges] from the Main Menu.
2. Tap on [Connect]
3. Tap screen and a selection menu will appear
4. Select desired signal
5. Use [<] or [>] to select the desired signals
Tap the star in the left corner to datalog that signal.
