ILLUSTRATED PARTS BREAKDOWN
Page F-7
Kawasaki Engine Shop Rebuild Manual
VALVE CAMSHAFT
Item Description E-Z-GO Part Number
Quantity
GOLF UTILITY
28 VALVE, INTAKE 603536 1 1
29 VALVE, EXHAUST 603537 1 1
30 RETAINER, VALVE SPRING 603538 2 2
31 COLLECT 603539 4 4
32 ARM, ROCKER 603540 2 2
33 TAPPET 603541 2 2
34 GUIDE, PUSH ROD 603542 2 2
35 ROD, PUSH 603543 2 2
36 SPRING, ENGINE VALVE 603544 2 2
37 CAMSHAFT-COMPLETE 607461 1 1
38 SCREW 603545 2 2
39 NUT 603546 2 2
40 SEAL OIL 603547 2 2
41 SPRING (NOT SHOWN) 603548 1 1
42 BOLT 603549 2 2
