ILLUSTRATED PARTS BREAKDOWN
Page F-9
Kawasaki Engine Shop Rebuild Manual
LUBRICATION
Item Description E-Z-GO Part Number
Quantity
GOLF UTILITY
43 PLATE, OIL RELIEF 603550 1 1
44 ASSY OIL PUMP 603552 1 1
45 COVER-PUMP 603553 1 1
46 ROTOR-PUMP, OUTER 603554 1 1
47 PIPE 603555 1 1
48 FILTER, OIL-FJ400D 607454 1 1
49 DIPSTICK OIL, LOW-SUSP 606390 1 1*
50 DIPSTICK OIL, HIGH-SUSP (NOT SHOWN) 606391 - 1*
51 RING SNAP 603556 1 1
52 PLUG 603557 3 3
53 BALL 603558 1 1
54 SPRING, OIL RELIEF 603559 1 1
55 BOLT 603560 2 2
56 BOLT, FLANGED 603561 1 1
57 O RING, 16MM 603562 3 3
58 SWITCH, OIL PRESSURE (NOT SHOWN) 608398 - 1
* Utility vehicles may be equipped with either high or low suspension. Please be sure to select the correct dipstick P/N for
your model.
