ILLUSTRATED PARTS BREAKDOWN
Page F-15
Kawasaki Engine Shop Rebuild Manual
CARBURETOR/CABLE BRACKETS
Item Description E-Z-GO Part Number
Quantity
GOLF UTILITY
76 GASKET, HD-CARBURETOR 603580 3 3
77 INSULATOR 603581 1 1
78 BRACKET, CHOKE CABLE 603583 1 1
79 BOLT, STUD 603584 2 2
80 CARBURETOR-AS03 607954 1 -
81 CARBURETOR-AS07 SPEC (NOT SHOWN) 607955 - 1
82 PLUG-PILOT JET 603585 1 1
83 JET-PILOT #44 608021 1 -
84 JET-PILOT #52 (NOT SHOWN) 607957 - 1
85 JET-MAIN #106 607956 - 1
86 JET-MAIN #104 607683 1 -
87 JET-MAIN #102 607684 - -
88 JET-MAIN #100 (NOT SHOWN) 607685 - -
89 VALVE-FLOAT 607686 1 1
90 FLOAT 607687 1 1
91 PIN, FLOAT 607688 1 1
92 GASKET, BOWEL 607689 1 1
93 ASSY, FLOAT CHAMBER 607690 1 1
94 GASKET, CHAMBER 607691 1 1
95 PLUG, CHAMBER 607692 1 1
96 BUSHING, THROTTLE ATTACH. 608023 1 1
To Next Page
