E-Z-GO SHUTTLE 2+2 Owner's And Service Manual

OPERATION AND SERVICE INFORMATION
Page 12
Owner’s Manual and Service Guide
Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings
PERIODIC SERVICE SCHEDULE
✓ Check ♦ Clean, Adjust, etc. ▲ Replace
To perform service that is listed in this schedule but not described in this manual, contact a local Service Representative or see
the Repair and Service Manual for this vehicle.
NOTE: Some maintenance items must be serviced more frequently on vehicles used under severe driving conditions
DAILY
BEFORE USE:
✓ Check service brake general operation
✓ Check park brake function
✓ Check warning device function in reverse
✓ Check tire condition
✓ Check overall vehicle condition
WEEKLY
TIRES
✓ Examine for cuts, excessive wear and pressure (See GENERAL
SPECIFICATIONS)
WHEELS ✓ Check for bent rims, missing or loose lug nuts
FUEL GAUGE ✓ Check for proper operation (at fueling), and fuel cap vent is free of dirt
ENGINE OIL ✓ Check and add if required - DO NOT OVERFILL
STARTER/GENERATOR BELT ✓ Check for tension, wear, cracks
MONTHLY - 20 HOURS (includes items listed in previous table & the following)
WIRING ✓ Check all wiring for loose connections and broken/missing insulation
ACCELERATOR ✓ Check for smooth movement - DO NOT LUBRICATE CABLE
SERVICE BRAKE
(MECHANICAL BRAKES)
✓ Conduct brake performance test
PARK BRAKE ✓ Check brake performance and adjust if required
CHOKE CABLE ✓ Check for smooth movement and adjustment - DO NOT LUBRICATE CABLE
CARBURETOR LINKAGE ✓ Check attachment, adjust as required
DIRECTION SELECTOR ✓ Check attachment, adjust as required
ENGINE ✓ Check for unusual noise, vibration, acceleration, oil leaks
COOLING FAN
✓ Check for build-up of foreign matter inside blower housing and fins, clean if
required
STEERING ASSEMBLY ✓ Check for abnormal play, tightness of all hardware
TIE ROD/LINKAGES ✓ Check for excessive play, bent components or loose connections
REAR AXLE ✓ Check for leakage, add SAE 30 oil as required
QUARTERLY - 50 HOURS (includes items listed in previous tables & the following)
FRONT AXLE ✓ Check for damage to axle and loose or missing hardware
Fig. 17 Periodic Service Schedule
