Owner’s Manual and Service Guide
GENERAL SPECIFICATIONS
Fig. 1 Vehicle Dimensions
NOTE: Shaded Area Indicates SHUTTLE 2+2
65.5 in. (166 cm)
92.5 in. (235 cm)
105 in. (267 cm)
46.5 in.
(118 cm)
Front
33.5 in. (85 cm)
Rear
38 in. (97 cm)
49 in.
(124 cm)
67 in.
(170 cm)
4.25 in.
(10.8 cm)
Ground
Clearance
Ref Dim 1-1
