Installation, Operation and Parts Manual
EE-6603S/EE-6603B
10
3.3 Dimensions
EE-6603B
Specification
RL
OL
L1
L2
EE-6603B.42L
4200
4442
1320
970
EE-6603B.48L
4800
5042
1520
1370
EE-6603B.51L
5100
5342
1520
1570
