Installation, Operation and Parts Manual
EE-6603S/EE-6603B
3.4 Technical data
Rated capacity of the main lift (kg)
Applicable wheel track of the main lift (mm)
Applicable wheel base of the main lift (mm)
Full raised time with rated load (s)
Full lowered time with rated load (s)
Hydraulic working pressure ( MPa )
Pneumatic working pressure (Bar)
INSTALLATION INSTRUCTIONS
4.1 Preparations before installation
4.1.1 Space requirements.
Refer to 3.3 for the dimensions of the lift. There must also be a clearance of at least 1 meter between the lifting platform and fixed
elements (e.g. wall) in all lifting positions. There must be sufficient space at the ends of the lifting platform for driving vehicles on and
off.
To stop vehicles colliding with the ceiling, it is advisable to fit an overhead light barrier in low ceiling buildings.
4.1.2 Foundations and connections
The user must have the following work performed before erecting the lift.
Construction of the foundation following consultation with the manufacturer’s customer service or an authorized service agent.
Routing of the wiring to the installation location. The user must provide fuse protection for the connection. Electrical system
connection must be done by qualified electricians. Requirements for power supply cable of the installation site: at least 2.5mm
2
wire core for 3Ph power and 4.0mm
2
wire core for 1Ph power.
Refer also to the corresponding information on the name plate and in the operation instructions. Before doing electrical
connection, make sure the lift is electrically adapt to the local power supply.
Routing of the compressed air connection to the installation location.
4.1.3 Foundations preparations
Please refer to Annex 1 for floor dimensions.
