EAE EE-6603S - Page 36

Installation, Operation and Parts Manual
EE-6603S/EE-6603B
36
Pos.
CODE
Description
Specification
Qty
17
204301012
Circlip
D35-GB894-1
4
18
410210141B
DOWN shaft
D6X40
4
19
206201013
Cotter pin
D2X10
8
20
612021003B
Rotation shaft of the main lift
6603B-A5-B1
4
21
202110004
Hex socket button head screw
M8X12-GB70_2
4
22
208106001
Straight oil cup
M8X1-JB9740_1
4
Pos.
CODE
Description
Specification
Qty
1
614901211
Main platform(42L,left, no track )
6603B-A4-B11-42LA
1
614901219
Main platform(42L,left , with track for rolling jacks)
6603B-A4-B11-42LCA
1
614901215
Main platform(48L,left, no track )
6603B-A4-B11-48LA
1
614901223
Main platform(48L,left , with track for rolling jacks)
6603B-A4-B11-48LCA
1
614901217
Main platform(51L,left, no track )
6603B-A4-B11-51LA
1
614901225
Main platform(51L,left , with track for rolling jacks)
6603B-A4-B11-51LCA
1
614901212
Secondary platform (42L,right,no track )
6603B-A4-B11-42LB
1
