EAE EE-6603S - Page 38

Installation, Operation and Parts Manual
EE-6603S/EE-6603B
38
Remark: for model S the two platforms are entirely the same.
Pos.
CODE
Description
Specification
Qty
1
614021514
Platform(42L.no track )
6603S-A4-B11
1
614021507
Platform(42L, with track for rolling jacks)
6603S-A4-B11
1
614021501
Platform(48L,no track )
6603S-A4-B11
1
614021506
Platform(48L, with track for rolling jacks)
6603S-A4-B11
1
614021502
Platform(51L.50T,no track )
6603S-A4-B11
1
614021509
Platform(51L, with track for rolling jacks)
6603S-A4-B11
1
3
614021503
Box A
6603S-A4-B1
2
4
410210173
Wheel retainer
6603B-A4-B2
2
5
614042008
Drive-on ramp
66035-A03-B02
2
6
410210111
Shaft A
6603B-A4-B9-C4
2
7
204301002
Circlip
D12-GB894_1
4
8
203101007
Hex nut
M12-GB6170
8
9
201102027
Hex head full swivel screw
M12X30-GB5783
8
