EAE EE-MR30 - Page 29

Installation, Operation and Parts Manual
EE-MR30
29
Pos.
Code
Description
Specification
Qty
1
320201201
Motor
230V-2.2KW -1PH-50HZ-2P
320201204
Motor
400V-2.2KW-3PH-50HZ-2P
320201001
Motor
220V-2.2KW-1PH-50HZ-2P
320201003
Motor
240V-2.2KW-1PH-50HZ-2P
320201004
Motor
380V-2.2KW-3PH-50HZ-2P
320201006
Motor
415V-2.2KW-3PH-50HZ-2P
2
330404006
Coupling
48mm（YBZ-F2.1D4H1/1-03）
1
3
203204102
Locking nut
FHLM-1/2-20UNF
1
