EAE EE-MR30 - Installation Attentions; General Installation Steps

Installation, Operation and Parts Manual
EE-MR30
13
4.1.5 Checking parts
Unfold the package and check if any parts missed as per the following list. Do not hesitate to contact us in case any parts missed, but if you
do not contact us and insist installing upon the lack of some parts, we as well as our dealers will not bear any responsibility for this and will
charge for any parts subsequently demanded by the buyer.
S/N
Name
Specification
Qty
1
MR30 Mechanical Assembly
MR30-00
1
2
Mobile kit
Optional
2.1
Wheel
MR30-A25-B1
2
2.2
Prop trough
MR30-A25-B2
1
2.3
All directional wheel
MR30-A25-B3
1
3
Feet protection fenders
MR30-A1-B7
2
4
Power and control unit
MR30-A24
1
5
Rubber pad
38x120x100mm
4
6
Hex socket cylinder head screw
M8x12
4
4.2 Installation attentions
4.2.1 Joints of oil hoses and wires must be well connected in order to avoid leakage of oil hose and looseness of electrical wires.
4.2.2 All bolts should be firmly screwed up.
4.2.3 Do not place any vehicle on the lift in the case of trial running.
4.3 General installation steps
Step 1: Place the lifting platform at expected installation site.
Please do read and understand this manual thoroughly before next step.
Step 2: Dismantle the package of the lifting platforms.
Remove the carton and packing films wrapped on the platform.
Avoid scratching the painting surface and hoses.
Step 3: Open the package of the control cabinet and take out accessories in it.
Step 4: Connect oil hoses.
Fix the oil hose fitting to the connector reserved on the hydraulic block.
Screw tight using an open spanner.
Attention: Do not contaminate the hydraulic components during the connection.
