Step 16: Fix door-opening protecting pads and feet protection fenders. .
4.4 Items to be checked after installation.
S/N
Check items
YES
NO
1
Screw torque of expansion bolts : 80-100Nm;
√
2
Rising speed ≥20mm/s;
√
3
Noise with rated load ≤75dB(A);
√
4
Grounding resistance: not bigger than 4Ω;
√
5
Height difference of the two carriages ≤5mm;
√
6
Mechanical locks are robust and synchronized when running with rated load ;
√
7
If the control button works as “hold to run”?
√
8
If limit switches work well?
√
9
If grounding wire is connected?
√
10
If rising and lowering smoothly?
√
11
If there is no abnormal notice during running with rated load?
√
12
If there is no oil leakage when running with rated load?
√
13
If expansion bolts, nuts or circlips is well secured?
√
14
If the max lifting height is 1900mm?
√
15
If Safety advices, name plate and logos are clear?
√
1.Cross socket flat head screw M8*16
2.Door protecting pad
3.Hex socket button head screw M8*12
4.Feet protecting fender
5.Lifting adapter
