Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
PRODUCTS DESCRIPTIONS
3.1 General descriptions
This is chassis supporting vehicle lift for road vehicles.
It is mainly composed by two posts, two carriages, four swing arms and a power and control unit.
It is driven by an electro-hydraulic system. The gear pump delivers hydraulic oil to oil cylinders and pushes upwards its piston. The
cylinder piston drives to raise the carriage and swing arms. It is equipped with mechanical safety locking unit which ensures no risks
of slipping off in case of hydraulic failure.
3.2 Construction of the lift
3.3 Technical data
Full rise time
(2.2kW motor )
