EAE EE62C-35T-E - Page 36

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
36
Pos.
Code
Descriptions
Specification
Qty
320201005
AC motor
400V-2.2KW -3PH-50HZ-2P
1
320201006
AC motor
415V-2.2KW -3PH-50HZ-2P
1
2
330404006
Coupling
48mm（YBZ-F2.1D4H1/1-03）
1
3
203204102
Locking nut
FHLM-1/2-20UNF
1
4
330311005
Solenoid valve
24DC(Keta)（LSV-08-2NCP-M-2H）
7
5
330302008
Non-return valve
YBZ-E2D3I1/1-03
7
6
330101113
Hydraulic block
LBZ-T2BK-8
1
7
207103019
Composite washer
M14
2
8
310101008
Transition connector
M14*1.5-G1/4 inside cone
1
9
210101014
Plug
Z3/8
1
10
201101100
Bolt
M6*50（NLJLD）
4
11
207101098
O-ring
109*5.3
1
12
330201025
Gear pump
2.5cc/r（CBKA-F2.5F）
4
13
204101005
Washer
M8
4
14
204201013
Spring washer
M8
2
15
202109072
Hex socket cylinder head screw
(with spring washer )
M8*85
2
16
330502013
Lid of oil tank (breather )
YBZ-BT-M30*2-B
1
17
202109144
Bolt
M5*18
4
18
204101003
Flat washer
M5
4
19
330405051
Plastic oil tank
10L-SLYX-10L-L-BX
1
20
210101013
Plug
M14*1.5
1
21
207101099
O-ring
5*1.8
4
22
203102003
Hex nut (thin, 6mm)
M10*1
1
23
330305015
Flow-restrictive valve
YBZ-E2D3I1/1-11A
2
24
330304010
Relief valve
DANRV-08-50
1
25
330301003
Buffer valve
HCF-Z1/4
1
26
330402006
Oil-returning pipe
YBZ-E2D3I1/1-09
1
27
330401013
Oil-sucking pipe
YBZ-SJYG350
1
28
330403003
Oil-sucking filter
YBZ-E2D3I1/1-10
1
