EAE EE62C-35T-E - Page 40

Installation, Operation and Parts Manual
EE62C-35T-E / EE62C-42T-E
40
Pos.
CODE
Description
Specification
Qty
3
203103005
Hex locking nut
M6
1
4
202109024
Hex head full swivel screw
M6*35
1
5
201102035
Hex head full swivel screw
M14*30
5
6
204101008
Flat washer
M14
5
7
204201007
Spring washer
M14
5
8
203101008
Hex nut
M14
5
9
420060010
Black foam tube
ID=22
1
10
614006006B
Crossbeam (out)
6214E-A21-B2
1
11
203101004
Hex nut
M6
8
12
204101004
Flat washer
M6
8
13
410010051
Rod of chain protection cloth
6254E-A1-B5
4
14
201102027
Hex head full swivel bolt
M12*30
8
15
204201006
Spring washer
M12
8
16
204101007
Class C flat washer
M12
8
17
203101012
Hex nut
M20
4
18
204101011
Flat washer
M20
4
19
410060033
Left support bracket
6214E-A22-B1
2
20
205101007
Bearing
2512
4
21
410044260
Pulley
62B-A1-B2
4
22
410060031B
Shaft for the upside pulley
6214E-A22-B2
2
23
410060023
Right support bracket
6214E-A22-B3
2
24
615006001
Chain protection cloth
6214E-A1-B3
2
25
614006007B
Extending post
6214E-A20
2
26
Power unit
1
27
203101006
Hex nut
M10
4
28
204201005
Spring washer
M10
4
29
204101006
Flat washer
M10
4
30
420040010
Anti-shock washer
6254E-A23
4
31
201103004
Hex head full swivel screw
M10*35
4
32
202109019
Hex socket cylinder head screw
M6*12
8
33
420540050
Protective cover for locking unit
at the power side post
62-A15
1
34
Control unit
1
35
614004893
Power side post （42T）
62C-A1-B1-42T
1
614004894
Power side post （35T）
62C-A1-B1-35T
1
36
204101004
Flat washer
M6
4
37
202101027
Cross socket cap head screw
M6*8
4
0
202109040
Hex socket cylinder head screw
M10*15
4
41
202111004
Hex socket flat head screw
M8*12
8
