37
TO EXPLORER
OTHER
DEVICE
12 VDC
BATTERY
BLACK WIRE
GROUND WIRES
WHITE WIRE
RED WIRE
TO +12V
OTHER
DEVICE’S
RECEIVE
DATA WIRE
EXPLORER’S
WIRES
OTHER DEVICE’S
WIRES
EXPLORER TRANSMITTING
NMEA DATA TO ANOTHER
DEVICE
TO EXPLORER
DGPS
RECEIVER
12 VDC
BATTERY
BLACK WIRE
GROUND WIRES
WHITE WIRE
RED WIRE
TO +12V
DGPS
RECEIVER’S
RECEIVE DATA
WIRE
(IF NEEDED)
EXPLORER’S
WIRES
EXPLORER RECEIVING
DATA FROM A DGPS
RECEIVER
GREEN WIRE
DGPS
RECEIVER’S
TRANSMIT
DATA WIRE
