Technical
specifications
General
Dimensions (mm): 256 x 193 x 106 (H x W x D)
Wall mounting (mm): c/c 160 x 125 (H x W)
Operating temperature: -30 °C to +50 °C
Weight: 1.5 kg
Charging
Charging power: 1.4–7.4 kW (6 A – 32 A)
Max output current: 32 A
Connection point: Type 2 socket (IEC 62196-2)
Number of phases: 1
Voltage: 230 V AC – single phase (±10 %)
Mains frequency: 50/60 Hz
Accuracy of built in energy meter (±2 %)
Load balancing of up to 3 units per circuit by integrated
wireless communication
Offline proof load-balancing
Automatic queuing system
Sensors and indicators
Light strip with LEDs showing the status of the charger
Touch button for manual adjustment
Temperature sensors in all main contacts
Connectivity
Built-in eSIM (LTE Cat M1/ 2G /GPRS)
WiFi 2.4 GHz b/g/n connection
Easee Link RF
TM
Control charging via Easee App
RFID/NFC reader (NFC / ISO 14443 and MIFARE Classic
®
)
OCPP 1.6 via our API
Protection
Integrated overload protection according to
EN IEC 61851-1:2019
Built-in RCD for ground fault protection (30 mA AC/
6 mA DC) according to EN 61008-1 and IEC 62955
Integrated protection for open / break fault condition in
supply PEN conductor according to BS 7671:2018/A1:2020
Degree of protection: IP54 (the backplate is IP22
without cover)
Impact resistance: IK10
Fire class: UL94
Insulation class: II
Overvoltage category III
Installation
Installation network: TT, TN-S, TN-C and TN-C-S
Installation circuit breaker: Max 40 A overload
protection. The short-circuit current at the charging
point (IkMax) must not exceed 10 kA. If required by the
installation method, type-A earth fault protection can
be used for the circuit.
Cable cross-section: up to 16 mm
2
(single cable)/
up to 10 mm
2
(parallel connection)
Cable diameter: 8–22 mm
Terminal tightening: 5 Nm
Cable strip length: 12 mm
