East Tester ET430 - Page 34

Hangzhou Zhongchuang Electronics Co., Ltd.
30
Impedance Z and phase angle

 100Hz, 120Hz, 1kHz, 10kHz
Range
Range of display
Accuracy Ze
Accuracy
e

Equivalent
mode
recommended
20MΩ
4.000MΩ~20.000MΩ
3.0%+10 digits
3.4°
Parallel
4MΩ
400.0kΩ~3.9999MΩ
1.2%+3 digits
0.7°
Parallel
400kΩ
40.00kΩ~399.99kΩ
0.3%+3 digits
0.2°
Parallel
40kΩ
4.000kΩ~39.999kΩ
0.25%+2 digits
0.1°
------
4kΩ
400.0Ω~3.9999kΩ
0.25%+2 digits
0.1°
Series
400Ω
40.00Ω~399.99Ω
0.25%+2 digits
0.1°
Series
40Ω
4.000Ω~39.999Ω
0.5%+3 digits
0.3°
Series
4Ω
0.4000Ω~3.9999Ω
2.0%+3 digits
1.1°
Series
0.4Ω
0.0000Ω~0.3999Ω
4.0%+3 digits
------
Series
 40kHz
Range
Range of display
Accuracy Ze
Accuracy
e

Equivalent
mode
recommended
20MΩ
4.000MΩ~20.000MΩ
7.0%+41 digits
4.0°
Parallel
4MΩ
400.0kΩ~3.9999MΩ
2.5%+3 digits
1.4°
Parallel
400kΩ
40.00kΩ~399.99kΩ
1.0%+4 digits
0.6°
Parallel
40kΩ
4.000kΩ~39.999kΩ
1.0%+4 digits
0.6°
------
4kΩ
400.0Ω~3.9999kΩ
0.5%+3 digits
0.3°
Series
400Ω
40.00Ω~399.99Ω
0.5%+3 digits
0.3°
Series
40Ω
4.000Ω~39.999Ω
0.7%+4 digits
0.4°
Series
4Ω
0.4000Ω~3.9999Ω
2.0%+6 digits
1.1°
Series
0.4Ω
0.0000Ω~0.3999Ω
5.0%+10 digits
------
Series
 100kHz
Range
Range of display
Accuracy Ze
Accuracy
e

Equivalent
mode
recommended
20MΩ
4.000MΩ~20.000MΩ
9.0%+20 digits
5.2°
Parallel
recommended
100mH
40.00mH∼399.99mH
2.5%+2 digits
0.0250
Parallel
40mH
4.000mH∼39.999mH
1.5%+2 digits
0.0150
Parallel
4mH
400.0uH∼3.9999mH
1.0%+2 digits
0.0100
------
400uH
40.00uH~399.99uH
1.0%+2 digits
0.0100
Series
40uH
4.000uH~39.999uH
1.5%+5 digits
0.0150
Series
4uH
0.000uH~3.999uH
4%+10 digits
------
Series
