Fault inspection and treatment
3.1 Alarm content and processing method
Item
Alarm contents
Processing method
1
Open the right door to ensure
safety before powering on!
In the case of tuning, you can turn off the detection in
the administrator settings interface.
2
The material is jammed when
sending the terminal.
Please check whether the mechanism of the terminal is
jammed or normal. The terminal is stuck, and the
terminal cylinder can be controlled by the manual
control interface to handle the clamped terminal. It is
also necessary to check whether the terminal has a
sharp edge or deformation.
3
The vibrating plate is
delivered without terminals.
Check whether the feeding of the vibrating plate is
normal or empty. If there is material, you need to check
whether the fiber amplifier is lit red or if the input X06
is red in the IO monitor. If the above is not available,
you need to look at the fiber amplifier setting value.
When there are terminals, the green number will be
greater than the red number.
4
The number of production
reaches the set value, please
return to the main screen to
clear the total number of
points!
Click on the alarm reset to return to the main screen
and continue to boot.
5
Emergency stop state, please
release the emergency stop
reset and then use.
Cannot be used in emergency state. If the alarm during
emergency stop is not pressed, input X13 (normal red)
can be viewed in IO monitoring. If it is not, it is a wire
break or the terminal rubber seat plug is loosened.
6
Peeling is abnormal. Check
for insufficient air pressure or
peeling depth.
Check whether the air pressure is low. For example,
when the air pressure is normal, check the input X07
(red when normal retracted) during IO monitoring. If it
is not, it is a wire break or the terminal rubber seat plug
is loosened.
7
The terminal is abnormal.
Check that the copper core is
loose or the copper core is
too long and the copper core
is bent.
Check if the wire bend does not penetrate the terminal.
If so, you need to switch to manual mode, enter the
manual control interface, jog to open the copper core
guide, and then use an elbow clamp and other tools to
clamp out the air pressure terminal, and then put it in a
good Terminal, reset copper core guide clip → main
screen → automatic mode, can produce.
