Eastsign MOT-M - Machine Structure and Components; Mechanical Accessories List; Electrical Accessories List

Eastsign
ROTARY HEAT PRESS MOT
-M USER MANUAL
11
4.5 Accessories list
Section
Name
Quantity
Series
Main Machine
(Mechanical)
Oil Drum
1
L15
Separate shaft
1
S1
Balance shaft
3
11, L17, L12
Supporting shaft
1
48
Adjusting shaft
2
L5, L6
Pressing shaft
1
L4,
Cylinder
1
L3,
Separate hand wheel
1
L2
Separate retarder
1
L1
Separate guide screw
1
Belt
1
43
Blanket
1
12
Main Machine (electric)
Loading bar
1
49
Colleting shaft
2
51
Tension knob
1
5
Control panel
1
2
Speed adjustor
1
3
Temperature control
device
1
4
Electrical button
3
7,8,9
Power indicator
1
6
Main Motor
1
L11
Air pressure adjustor
1
L10
Cover
1
L18
Motor
1
52
Speed adjustor
1
50
Fan
3
54, L20, L23
Air Pressure Switch
2
43, 44
AC contactor
3
L20,L21,L22
