EasySplicer mk2 - Technical Specification

Technical specification:
Weight: 800g
Dimensions: 230x98x53 mm
Alignment: Axial: Automatic
Radial: Fixed v-groove
Fusion technique: Arc fusion
Process: Automatic
Typical Loss: SMF 0.03dB
MMF 0.01dB
Splice Programs: 3 pre-defined:
–
Singlemode
–
Multimode
–
OM1
Fiber handling: Fiber holders, 3 pairs (250-BLACK, 900-BLUE
and 900-RED loose coat/loose tube).
Typical cycle time: 7s + 35s (splice cycle + oven cycle).
Display: 2.8” Color TFT
Magnification: Camera 140x
Heat oven: Ceramic heater built in.
Sleeve dimensions: Max 60mm length, 2-5mm diameter.
Power source: Battery: 7.4V/3400mAh. Li-Ion type. Built in.
Communication: USB, mini USB-plug.
Memory: Internal 1MB, External SD-card up to 32GB, FAT32 file system.
Power supply: 100-240V AC / 6V DC / 1.5A
Operating environment: Temperature 0˚C to 45˚C
Humidity max 95% RH,
non-condensing
Storage environment: Temperature -20˚C to 45˚C
Humidity max 98% RH,
non-condensing
