Eaton 9395 UPS - Figure 4-12. ISBM Section Intercabinet Power Terminal Locations - Common Rectifier Feed, Continuous Static Switch

UPS SYSTEM INSTALLATION
Eaton 9395 UPS (450–825 kVA) Installation and Operation Manual S 164201725 Rev 4 www.eaton.com/powerquality
4-16
(See Figure 4‐13
for detail.)
AC Input to UPMs
AC Output
from UPMs
Phase C
Phase A
Phase B
Neutral from UPMs
(See Figure 4‐17
for detail.)
(See Figure 4‐17 for detail.)
Phase A
Phase C
Phase B
(See Figure 4‐16 for detail.)
AC Input Breaker CB1
DC Input to UPMs
–
(E5)
(See Figure 4‐16 for detail.)
DC Input to UPMs
+
(E4)
Figure 4‐12. ISBM Section Intercabinet Power Terminal Locations – Common Rectifier Feed, Continuous Static Switch
