Eaton 9PHD - Page 16

EBC model F G
90...100 kW 50 50
110...150 kW 70
160...200 kW 95
210...250 kW 120
260...300 kW 150
Cable harness strain relief, power inlets To be defined and drilled at the site
Cable harness strain relief, signal inlets Recommended: M16, Ø 5...10 mm
3)
DC power and protective bonding cable type Rubber insulated copper, 450/750 V,
style: H07
Signal wire connector size and torque 6 mm
2
, 0.8 Nm
Signal wire size and type 4 x 0.75 mm
2
, 300/500 V
1)
Connectors for daisy chain are equal in number and size.
2)
Cable (between the equipment cabinets, two insulating layers) manufacturer
types as an example:
BETAflam 145 flex 600/1000 V / Toxfree ZH RZ1-K HF / Helkama H-Flex PWR PUR
0,6/1 kV / Helkama LKM-HF 0,6/1 kV
50 mm
2
15 mm
2 x 50 mm
2
28-29 mm
70 mm
2
16.4-17 mm
2 x 70 mm
2
31.5-33 mm
95 mm 17.6-19.5 mm
2 x 95 mm
2
36.7 mm
120 mm
2
19.4-21.5 mm
150 mm
2
21.5-24.5 mm
Conductor (for internal cabling in the equipment cabinet, one insulating layer)
H07V2-K 450/750 V PVC / BETAtherm 145, HF / NSGAFÖU 1,8/3 kV HF very flexible
25 mm
2
o.d 9.2-13 mm
50 mm
2
o.d 13-15.5 mm
70 mm
2
14-17 mm
95 mm
2
16-17 mm -19.5 mm
120 mm
2
18-19.5 mm - 21.5 mm
150 mm
2
20-21 mm - 23 mm
Eaton 9PHD Accessory Cabinets TFC-A, EBC-F
and EBC-G User's and installation guide
©
Eaton Corporation plc 2022. All rights reserved. Document ID: P-164000538 16 (63)
