General symbol for pro-
hibited action
No smoking
Limited or restricted ac-
cess
1.2.3 Mandatory action symbols
These symbols are used to indicate an action that must be taken.
General symbol for man-
datory action
Disconnect from power
source
Read the manual or in-
structions
1.3 Conventions used in this document
This document uses the following type conventions:
• Bold type highlights important concepts in discussions, key terms in
procedures and menu options, or represents a command or option that you
type or enter at a prompt.
•
Italic type highlights notes and new terms when they are defined.
• Screen type represents information that appears on the screen or LCD.
1.4 Glossary
Eaton manuals use the following acronyms to refer to Eaton UPS products or
their parts.
Table 1: Glossary of acronyms
ABM Advanced Battery Management
BIB Bybass Input Breaker
EBC External battery cabinet
EMBS External Maintenance Bypass Switch
Eaton 9PHD Accessory Cabinets TFC-A, EBC-F
and EBC-G User's and installation guide
©
