2. Connect the fan failure signal (transformer cabinet terminals X5:3– X5:4) to
the UPS cabinet’s fan failure signal inputs (UPS X10:18– X10:20).
• If the UPS is equipped with internal transformers, the signals are
connected to UPS terminals X10:18 and X10:20.
• If the UPS is not equipped with an internal transformer, the signals are
connected to UPS terminals X10:18 and X10:19.
CAUTION
The UPS signal inputs must be configured by an Eaton authorized Customer
Service Engineer or by a qualified service officer authorized by Eaton.
3.8 Installation compatibility of the EBC-F, EBC-G and
TFC-A
EBC-F and EBC-G are compatible with the Eaton UPS product line. The EBC-F
is designed to be used with an uninterruptible power supply (UPS) that is rated
up to 100 kW output power and the EBC-G with up to 200 kW output power.
Other UPS products may not be fully compatible with EBC-F, EBC-G and TFC-
A. Refer to the UPS manual for the requirements for the external battery supply.
Eaton 9PHD Accessory Cabinets TFC-A, EBC-F
and EBC-G User's and installation guide
©
Eaton Corporation plc 2022. All rights reserved. Document ID: P-164000538 52 (63)
