Eaton 9PHD - Environmental Specifications

Battery voltage 432 V (36 blocks) or 480 V (40 blocks)
Minimum battery short circuit current NZMN2-A200-S07-DC 950 A
NZMN2-A400-S07-DC 2150 A
Battery recharge During storage, for 48 hours at the interval
stated on the battery recharge label of the
EBC.
Recharge profile ABM or float charge
End of discharge voltage
1.67 VPC to 1.75 VPC, configurable or
automatic (load adaptive)
Charge current Configurable:
30–50 kW units
Configurable 0...29.3 A At > 40 kVA
load automatically limited to 16.5 A.
1)
80–100 kW units
Configurable 0...58.9 A At > 80 kVA
load automatically limited to 33A.
1)
120–150 kW units
Configurable 0...87.9 A At > 120 kVA
load automatically limited to 49.5A.
1)
160–200 kW units
Configurable 0...117.2 A At > 160 kVA
load automatically limited to 66 A.
Note that the maximum charge
current is 29.3 A per UPM.
1)
Battery start option Yes
1)
In models with the IP54 option, charging power is limited to 80% of maximum power.
For example, 40 kVA is reduced to 32 kVA (16.5 A).
5.3 Environmental specifications
Recommended storage temperature range From -20 °C to +25 °C in the protective
package
Ambient operating temperature range From 0 °C to +40 °C
1)
Recommended operating temperature
range
From +20 °C to +25 °C
Relative humidity range 5 to 95%, no condensation allowed
1)
Operating at 0 °C reduces calculated autonomy time and 40 °C reduces lifetime ex-
pectancy.
