5.4 Cabinet specifications
IP23/33 cabinet dimensions (WxDxH) TFC-A and EBC-F: 625 x 937 x
1,958/1,978
EBC-G: 1,118 x 1,091 x 1,958/1,978
IP54 cabinet dimensions (WxDxH) TFC-A and EBC-F: 625 x 987 x
1,958/1,978
EBC-G: 1,118 x 1,145 x 1,958/1,978
Cabinet weights (without batteries) EBC-F: 266 kg
EBC-G: 750 kg
TFC-A: 720 kg
Cabinet weights with batteries EBC-F: 970 kg
EBC-G: 2,560 kg
