Instructional Lea et IL03901003E
Effective May 2011
DS7 series soft start controllers, Frame 1 (4–12A)
Service
For additional information on this product, please call the Eaton
Technical Resource Center at (877) 386-2273 or visit our Web site at
www.eaton.com.
Service and repair is available from Eaton or several factory
authorized regional service centers. Please contact the Eaton
Product Integrity Center at (800) 345-0434 for the location nearest
to you.
For field service or start-up assistance 24 hours a day, 7 days a
week, please call (800) 498-2678.

Eaton DS7 Series Specifications

General

Type	Soft Starter
Control Voltage	24 V DC
Input Frequency	50/60 Hz
Protection Class	IP20
Cooling Method	Natural Convection
Protection Features	Overload
Communication	Modbus RTU
Operating Temperature	-25 to 60°C
Dimensions	Varies by model
Weight	Varies by model
