Stationary Arcing
Contacts
Molded Base
Arcing
Contact
Spring
Main Contact
Spring
Hinge Spring
Insulating Link
Insulating Link
Adjusting Nut
Pivot Block
Moving Main
Contact
Assembly
Figure 3-4 Type DSII-308 Pole Unit Assembly (Front View)
Upper Terminal
Lower Terminal
(Sensor Removed)
Figure 3-5 Type DSII-308 Pole Unit Assembly (Rear View)
Effective July 2010
Instructional Book IB694C694-03
19
EATON CORPORATION www.eaton.com
