Figure 3-8 DSII Interphase Barriers Being Removed Figure 3-9 DSII Arc Chute Being Removed
Terminal
Block
Typical
Current
Sensor
Rating
Plug
Protection
Function
Settings
Trip Actuator
(600 Ohms
Nominal
Resistance)
Typical DSII Type
Circuit Breaker
Sensors
** Alternate ground locations
may be required to meet
installation requirements
Figure 3-10 Typical Type DSII Tripping System Diagram
Typical Digitrip RMS III Trip Unit Assembly
Effective July 2010
Instructional Book IB694C694-03
21
EATON CORPORATION www.eaton.com
