Eaton DSII Series User Manual

Shunt Trip Device Ratchet Wheel Reset Spring
Trip Shaft Hold Pawl Closing Spring Anchor
Roller Constraining Link Drive Plate Pole Shaft
Trip Latch Emergency Charge Pawl Motor
Close Cam Oscillator Emergency Charge Handle
Stop Roller Crank Shaft Motor Crank and Handle
Spring Release Latch Emergency Charge Device Moving Contact Assembly
Spring Release Device Crank Arm Insulating Link
Oscillator Pawl Closing Spring Main Drive Link
Figure 4-4 Principal Parts in Power Operated Mechanism (Close Spring Shown in Charged Position)
Effective July 2010
Instructional Book IB694C694-03
32
EATON CORPORATION www.eaton.com
