Eaton DSII Series User Manual

Close Cam Oscillator Pawl Oscillator Bushing
Pawl Lifter Oscillator Oscillator Spring
Crank Arm Drive Plate Closing Spring
Spring End Motor Crank Roller Crank Shaft
Ratchet Wheel Ratchet Wheel Pin Hold Pawl
Figure 4-6 Power Operated Spring-Charge Details
a. Spring Charged
Note: Main cam position for this crank shaft position is shawn in Fig. 4-7
Effective July 2010
Instructional Book IB694C694-03
34
EATON CORPORATION www.eaton.com
