Page #41 background imageLoading...
Page #41 background image
a. Shutter in Normal Position, Trip Plate
in Untripped Position
Shutter Push Tab
Shutter
Levering Device Worm Shaft
Shutter Lower Projection
Shutter Pivot Pin
Pole Shaft
Levering Device Shaft
Trip Shaft
Trip Shaft Pin
Tripping Tab
Trip Plate
Trip Plate Hook
Levering Device Crank Handle
b. Shutter, Trip Plate Held in Tripped Position
Figure 4-11 Shutter, Trip Plate and Trip Shaft Relationship
Effective July 2010
Instructional Book IB694C694-03
41
EATON CORPORATION www.eaton.com
