Eaton DSII Series User Manual

a. Close-Release Interlock b. Breaker in Remove Position
c. Breaker in Connect Position (Without
Interlock Screw, See Paragraph 4-5.7
d. Breaker in Connect Position (With
Interlock Screw, See Paragraph 4-5.7
Interlock Plate Assembly Pin “A”
Drive Pin Pin “B”
Interlock Screw Close Bar
Levering Device Shaft Close Bar Pivot
Narrow Slot Close Bar Cam
Wide Slot Levering Device Arm
Figure 4-13 Close-Release Interlock to Discharge Springs on Levering Out
Effective July 2010
Instructional Book IB694C694-03
45
EATON CORPORATION www.eaton.com
