ELC Programming Manual
FOR MORE INFORMATION VISIT: WWW.EATON.COM MN05003003E
2-140
Applicable to
Device Range Type Address
ELC-PB,
ELCB-PB
ELC-
PC/PA/PH
ELC-PV,
ELCM-PH/PA
D 000 ~ 256 word 1000 ~ 10FF
D 256 ~ 511 word 1100 ~ 11FF
D 512 ~ 767 word 1200 ~ 12FF
D 768 ~ 1,023 word 1300 ~ 13FF
D 1,024 ~ 1,279 word 1400 ~ 14FF
D 1,280 ~ 1,535 word 1500 ~ 15FF
0 ~ 1,311
D 1,536 ~ 1,791 word 1600 ~ 16FF
D 1,792 ~ 2,047 word 1700 ~ 17FF
D 2,048 ~ 2,303 word 1800 ~ 18FF
D 2,304 ~ 2,559 word 1900 ~ 19FF
D 2,560 ~ 2 815 word 1A00 ~ 1AFF
D 2,816 ~ 3,071 word 1B00 ~ 1BFF
D 3,072 ~ 3,327 word 1C00 ~ 1CFF
D 3,328 ~ 3,583 word 1D00 ~ 1DFF
D 3,584 ~ 3,839 word 1E00 ~ 1EFF
D 3,840 ~ 4,095 word 1F00 ~ 1FFF
D 4,096 ~ 4,351 word 9000 ~ 90FF
D 4,352 ~ 4,607 word 9100 ~ 91FF
D 4 608 ~ 4863 word 9200 ~ 92FF
D 4,864 ~ 5,119 word 9300 ~ 93FF
0 ~ 4,999
D 5,120 ~ 5,375 word 9400 ~ 94FF
D 5,376 ~ 5,631 word 9500 ~ 95FF
D 5,632 ~ 5,887 word 9600 ~ 96FF
D 5,888 ~ 6,143 word 9700 ~ 97FF
D 6,144 ~ 6,399 word 9800 ~ 98FF
D 6,400 ~ 6,655 word 9900 ~ 99FF
D 6,656 ~ 6,911 word 9A00 ~ 9AFF
D 6,912 ~ 7,167 word 9B00 ~ 9BFF
D 7,168 ~ 7,423 word 9C00 ~ 9CFF
D 7,424 ~ 7,679 word 9D00 ~ 9DFF
D 7,680 ~ 7,935 word 9E00 ~ 9EFF
D 7,936 ~ 8,191 word 9F00 ~ 9FFF
D 8,192 ~ 8,447 word A000 ~ A0FF
D 8,448 ~ 8,703 word A100 ~ A1FF
D 8,704 ~ 8,959 word A200 ~ A2FF
D 8,960 ~ 9,215 word A300 ~ A3FF
D 9,216 ~ 9,471 word A400 ~ A4FF
D 9,472 ~ 9,727 word A500 ~ A5FF
D 9,728 ~ 9,983 word A600 ~ A6FF
D 9,984 ~ 9,999 word A700 ~ A70F
-
-
0 ~ 9,999
