ELC-PV Controllers
*1: K-1 refers to the default setting is non-latched.
General Latched
Special auxiliary
relay
Latched
M0~M499 M500~M999 M1000~M1999 M2000~M4095
Non-latched
(default)
Latched (default) Latched (default)
M
Auxiliary
relay
Start: D1200 (K500)
End: D1201 (K999)
Some are latched
and they cannot
be changed.
Start: D1202
(K2000)
End: D1203
(K4095)
100 ms 10 ms 10ms 1 ms 100 ms
T0 ~T199 T200~T239 T240~T245 T246~T249 T250~T255
Non-latched
(default)
Latched (default)
T
Timer
Start:
D1204 (K-1)*1
End:
D1205 (K-1)*1
Start:
D1206 (K-1)*1
End:
D1207 (K-1)*1
Accumulative
latched
16-bit count up 32-bit count up/down
32-bit high-
speed count
up/down
C0~C99 C100~C199 C200~C219 C220~C234 C235~C255
Non-latched
(default)
Latched
(default)
Non-latched
(default)
Latched
(default)
Latched
(default)
C
Counter
Start: D1208 (K96)
End: D1209 (K199)
Start: D1210 (K216)
End: D1211 (K234)
Start: D1212
(K235)
End: D1213
(K255)
General Latched Special Latched General
S0~S9 S10~S19 S20~S499 S500~S899 S900~S1023
Non-latched (default) Latched (default)
S
Step
relay
Start: D1214 (K500)
End: D1215 (K999)
Latched
General Latched Special register Latched
D0~D199 D200~D999 D1000~D1999 D2000~D9999
Non-latched (default) Latched (default) Latched (default)
D
Register
Start: D1216 (K200)
End: D1217 (K999)
Some is latched,
and cannot be
changed
Start: D1218 (K2000)
End: D1219 (K9999)
K0-9999
File
Register
Latched
