The values of T20~T27 are mapped to Modbus Registers: H0614~H061B
Command message:
“: 01 03 06 14 00 08 DA CR LF”
Field name ASCII Hex
STX : 3A
Slave Address 01 30 31
Function code 03 30 33
Starting Address High 06 30 36
Starting Address Low 14 31 34
Number of Points High 00 30 30
Number of Points Low 08 30 38
LRC checksum DA 44 41
END CR LF 0D 0A
Response message:
“: 01 03 10 00 01 00 02 00 03 00 04 00 05 00 06 00 07 00 08 C8 CR LF”
Field name ASCII Hex
STX : 3A
Slave Address 01 30 31
Command code 03 30 33
Bytes Count 10 31 30
Data Hi (T20) 00 30 30
Data Lo (T20) 01 30 31
Data Hi (T21) 00 30 30
Data Lo (T21) 02 30 32
Data Hi (T22) 00 30 30
Data Lo (T22) 03 30 33
Data Hi (T23) 00 30 30
Data Lo (T23) 04 30 34
Data Hi (T24) 00 30 30
Data Lo (T24) 05 30 35
Data Hi (T25) 00 30 30
Data Lo (T25) 06 30 36
Data Hi (T26) 00 30 30
Data Lo (T26) 07 30 37
Data Hi (T27) 00 30 30
