Eaton ePDU - COM Ports

Table 6. Settings Potentially Affected by Power Cycle
Warning or Alarm Target Range
INPUT Low voltage warning 70%*V-rating <= V-setting <= 95%*V-rating
INPUT Over voltage warning 105%*V-rating <= V-setting <= 130%*V-rating
INPUT Over voltage critical 105%*V-rating <= V-setting <= 130%*V-rating
INPUT Over current warning 25%* I-rating <= I-setting <= 110%* I-rating
INPUT Over current critical 80%* I-rating <= I-setting <= 110%* I-rating
BRANCH Low current warning: I-setting <= 100%*I-rating
INPUT Over current warning I-setting <= 100%*I-rating
INPUT Over current critical I-setting <= 100%*I-rating
OUTLET Low voltage warning 70%*V-rating <= V-setting <= 95%*V-rating
OUTLET Over voltage warning 105%*V-rating <= V-setting <= 130%*V-rating
OUTLET Over voltage critical 105%*V-rating <= V-setting <= 130%*Voltage rating
OUTLET Over current warning I-setting <= 100%*I-rating
OUTLET Over current critical I-setting <= 100%* I-rating
NOTE The I-rating for C13 outlets is 10A. The I-rating for C19 outlets is 16A.
Troubleshooting
Eaton Advanced ePDU Troubleshooting Guide P-164000140—Rev 1 www.eaton.com/ePDU 9
COM Ports
This section provides COM port troubleshooting for the Advanced ePDU models. Table 7 lists fault conditions,
potential causes, and possible troubleshooting actions you can take in response to problems.
