Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
761 Load Voltage
Angle (L-L)
----- Degrees
Degrees View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Load Voltage Angle from Line to
Line.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
762 Source Voltage
Angle (L-N)
----- Degrees
Degrees View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage Angle from Line
to Neutral.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
763 Source Voltage
Angle (L-L)
----- Degrees
Degrees View NA NA NA NA NA
•This is a Delta Calc instantaneous metering value for the Source Voltage Angle from Line
to Line.
•On a multi-phase control, the metering values for each phase can be viewed by scrolling
with the right arrow.
800 Protocol / Port
Type
Serial DNP
--- View Modify NA Serial DNP NA NA
•Protocol and Port setting for Com 1. Not all options are resident on the control, some
will require additional hardware to enable. The available protocol options will display
according to port type.
•Possible options for a particular configuration include: Disabled; DNP / Serial; DNP /
Ethernet; IEC 101 / Serial; IEC 104 / Ethernet; 2179 / Serial; Modbus / Serial; Modbus /
Ethernet.
800 LoopShare
Communications
Disabled
--- View Modify NA Disabled NA NA
•This will enable or disable LoopShare Communications for Com 1. The options include:
Disabled; Enabled.
800 ProView NXG
Session
Disabled
--- View Modify NA Disabled NA NA
•This will enable or disable sessions with ProView NXG for Com 1. The options include:
Disabled; Enabled.
800 ProView NXG
Address
XXXXX
--- View Modify NA 65519 0 65519
•The Com 1 address for communications with ProView NXG is set here.
800 Ethernet Switch
On Com 1
Disabled
--- View Modify NA Disabled NA NA
•This will enable or disable the Ethernet switch when it is available on Com 1. The
options include: Disabled; Enabled.
102
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
