Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
800 Serial Bridge
Mode
Disabled
--- View Modify NA Disabled NA NA
•This parameter enables the Serial Bridge communications mode. The options include:
Disabled; Enabled.
•The Serial Bridge feature enables the use of a RS-232 communications card to facilitate a
connection between a master station and a local serial FO communications loop for DNP3
protocol. This functionality is similar to that available on the CL-6 control using the
serial RS-232/FO communications board.
801 Serial Baud Rate
9600 BPS
--- View Modify NA 9600 BPS NA NA
•This is the Com 1 Serial Communications Baud Rate setting. The options available are:
300 BPS; 600 BPS; 1200 BPS; 2400 BPS; 4800 BPS; 9600 BPS; 19200 BPS; 38400 BPS; 57600
BPS; 115200 BPS.
801 Serial Parity
None
--- View Modify NA None NA NA
•This sets for Com 1 the data parity parameter to be used on the serial communications
channel.
•The available options are: None; Odd; Even
801 Serial CTS
Support
Disabled
--- View Modify NA Disabled NA NA
•This setting determines for Com 1 if CTS/RTS handshaking will be used to control the
serial communications channel.
•The available options are: Disabled; Enabled
801 Serial Tx
Enable Delay
XXXX mSec
MilliSec View Modify NA 5 0 3000
•For Com 1, when the control is set for transmit control handshaking, a delay may be
required between the time when the transmission is enabled to when data is transmitted.
•Example: If the transmit enable were used as a keying device for a transmitter or modem,
a “warm-up” period may be necessary before data can be transmitted.
•See Figure 19.
103
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
